I thought I had already posted these pictures of my struggles with the removal of the top of the centre console but I cannot find them anywhere so I will attempt to repost them.

I have been finding Jaguar electrical connectors to be tediously overly complicated so I thought I would provide some clarity on the connectors to the cigarette lighter and the Sport and DSC buttons. Hopefully others could use the pictures to help them with centre console issues.

Anyways, here goes again.



I did not supply information on the Sport and DSC button connections in the above because I was worried that I was overburdening the data transmission. I will try to show that information here.
