Default DG Automatic Gearbox Rear Extension Removal
Hi,

I have attached photos of the original workshop manual for removing the rear extension unit from a DG250 gearbox, I do have the entire manual so if anyone needs any other photos please drop me a PM.

Attached Thumbnails DG Automatic Gearbox Rear Extension Removal-20171230_085013.jpg   DG Automatic Gearbox Rear Extension Removal-20171230_085146.jpg   DG Automatic Gearbox Rear Extension Removal-20171230_085154.jpg   DG Automatic Gearbox Rear Extension Removal-20171230_085205-0-.jpg   DG Automatic Gearbox Rear Extension Removal-20171230_085218.jpg
