Hello, I seem to have a problem with the catalysts of my 2003 4.2L XJ8, which seem to start falling apart internally. After >350.000 km I admit they do have a certain right to retire, but it means I need some replacement.
New OEM catalysts are no longer available as far as I leant from Jaguar here in Germany, and they also would seem forbiddingly expensive.

2nd hand also seems to be extremely rare, simply due to the low production volume of the X350.

I found some cheaper direct fit replacements on eBay (e.g. Pair Catalytic Converters for Jaguar Super V8, Vanden Plas, XJ8, XJR, XK8 4.2L ) but don't really trust these to not fall apart again after a few months or light the MIL due to insufficient precious metal coating.
Does anyone have a little longer term experience with replacement catalysts like the ones linked above? Maybe even positive experience?


I also asked in the UK forum already, but so far the helpful hints there unfortunately haven‘t lead to any available catalysts.



Hi Aix,

according to this

https://parts.jaguarlandroverclassic.../brand/jaguar/

at least the left hand side catalyst is still availlable.

Best regards from Germany

Thomas



Hi Aix,

I have a XJR and one of my Cats disintegrated and started rattling itself to bits. I fitted a second hand cat from a normally aspirated 4.2 and have had no issues with it since. Took a while to find it and the connection orientation was different, so had to cut off bits of the old one and weld onto the replacement.



250 bucks from canada poor fitment but works and turns off the 420 430 for at least a year

will get you past most emissions tests unless tuv wants to make your life hell for aftermarket parts



Well, thanks for the replies.

Thomas, I found the one existing side from OEM now also on the jaguarlandroverclassic page. A bit over 1000 pounds to order here from Germany, so that will be benchmark. Plus of course the problem to get the second one.

paddyx350, "took a while to find" describes exactly my problem. I found someone who freshly put an X350 exhaust system into classifieds in Germany, when I directly asked about the catalysts he wrote back they had been sold in <24h and never made it to the public.So it really needs a lot of good fortune that one of these accidentally runs in front of my car but I keep looking

xalty, could you be a bit more specific, where you got these budget catalysts from Canada?



Are there any suitable CAT options available for the 4.2 S-Type that you can perhaps retrofit?
See some aftermarket options on eBay for the S-Type, so was just wondering if that might be an option for you to explore.



You could also look here:

https://www.exco.nl/de/ersatzteile/n...2c19639-7743-p

or here, but they are expensive:

https://www.xkstore.at/de/x350-358-x...st-system.html

Best regards,

Thomas
