Cps
#1
Cps
My 90 VDP 86k wouldn't start last week. I changed the fuel pump, I have lightning sparks as well. My question is this. Can you have spark and still have a bad crank position sensor? Remember this car sat for 6-7 years before I bought it, and it took me forever to get it started back in Dec 2010. As I recall, I did have spark. I pulled a CPS from a junker and the car was great until last Monday. My suspicion is that CPS...again.
#2
#4
#5
Remeber the triangle.
Air, Fire, Fuel.
If your getting air and fire (spark) then its the fuel.
If shes turning over and not starting Id look at the pump first, and work forwards from there.
You already replace the pump and filter. Have you confirmed that the injectors are fireing?.
You can easily confirm the dist and rotor by unhooking one of the leads from a sparkplug, and hold it in your fingers. Then have someone try to start the car. IF you get a sharp shock, you can bet the plugs are getting fire! (this was a way I mistakenly did it. My intention was to watch the spark plug fire but my helper was a littler too enthusiastic and turned the key too soon. lol)
Air, Fire, Fuel.
If your getting air and fire (spark) then its the fuel.
If shes turning over and not starting Id look at the pump first, and work forwards from there.
You already replace the pump and filter. Have you confirmed that the injectors are fireing?.
You can easily confirm the dist and rotor by unhooking one of the leads from a sparkplug, and hold it in your fingers. Then have someone try to start the car. IF you get a sharp shock, you can bet the plugs are getting fire! (this was a way I mistakenly did it. My intention was to watch the spark plug fire but my helper was a littler too enthusiastic and turned the key too soon. lol)
Last edited by AdrianSw; 09-08-2011 at 02:51 PM.
#6
Issue is spark, not fuel
lol. No thank you. This issue has me chasing like a dog. I bought one of those spark testers that plugs into the spark wire, then you ground the other end, you can even measure spark. I was able to set it up so I could see it when i was in the car. No spark. I replaced the coil, still no spark. I replaced the CPS, distributor cap and rotor, no spark. Yes I did put another pump, new filter and fuel regulator on the car. I have voltage going to the ignition amplifier. I have gone out this morning and got another amplifier, coil and yet another CPS, actually this CPS shows a much higher reading on the meter. I bought a brand new rotor and distributor cap as well. As soon as I get the energy, i will go and replace everything again.
#7
90MY coil amp crank position sensor testing
mrtalkradio,
Instead of bouncing back and forth between threads, I've decided to respond to your prior post here, on your thread.
Lest I forget (everyone knows #1 but I'm just checking),
th_1990VDPCrankSensor-schem.png?t=1315671067
(click thumbnail to see 90MY Crank Sensor schematic)
Dynamic crank position sensor test
Crankshaft sensor wires, R (red) and U (blue), connect to the LOW POWER ECU at pins LI59-13 and LI59-24.
I'm reminding myself here that you should find the WB wire (white/black tracer) connecting the amplifier to the coil, connect a voltmeter to the coil at its negative (-) terminal end and ground, set the scale to AC volts, have someone crank the engine and check to see if you are getting a fluctuating signal. You most probably are not.
The amplifier acts as a switch, periodically shunting the coil to ground. The capacitor is provided to smooth out the transients (or spikes) in coil's voltage waveform.
o
Instead of bouncing back and forth between threads, I've decided to respond to your prior post here, on your thread.
Originally Posted by mrtalkradio
... My car was running beautifully, you didn't know it was running at a stop. I shut it off on Aug 30th and she hasn't started since. I haven't bought brand new parts, but have been taking them off other vehicles at the junk yard and using a meter and power source to be sure they work. Today it is dancing on my last nerve. 3 Different CPS's, 3 Different coils, new pump, filter, regulator and amplifier. I haven't spark! I have voltage to the ignition amp, I have 18+ volts to the positive and negative wires that attach to the coil. Thats where it stops, I have no spark from the output of the center of the coil. I have great resistance from the pos terminal and center of coil..7.8, The reading on all 3 coils on the meter when OHMing them out, across the pos and neg terminal is 000. I am stuck. I have read all trick has taken the time to post, but until I get spark out of the coil, I can't do anything. Anyone want to throw a horseshoe here?
- did you check to see that the Inertia Switch is NOT tripped? (I don't know what all this switch kills on a 90MY)
- did you test for a good coolant temperature sensor and connection?
th_1990VDPCrankSensor-schem.png?t=1315671067
(click thumbnail to see 90MY Crank Sensor schematic)
Dynamic crank position sensor test
Crankshaft sensor wires, R (red) and U (blue), connect to the LOW POWER ECU at pins LI59-13 and LI59-24.
- Find your ECUs,
- locate the LOW POWER ECU,
- locate the afore mentioned pins,
- connect the probes of a voltmeter set on the AC function to these pins,
- have someone crank the engine, and
- check to see if you are getting a pulsed signal.
- the wiring from the ECU to sensor connector,
- the gap between sensor and gear teeth (should be 0.018 to 0.042 inch) or
- the Crank Sensor itself.
I'm reminding myself here that you should find the WB wire (white/black tracer) connecting the amplifier to the coil, connect a voltmeter to the coil at its negative (-) terminal end and ground, set the scale to AC volts, have someone crank the engine and check to see if you are getting a fluctuating signal. You most probably are not.
The amplifier acts as a switch, periodically shunting the coil to ground. The capacitor is provided to smooth out the transients (or spikes) in coil's voltage waveform.
o
Trending Topics
#8
- did you check to see that the Inertia Switch is NOT tripped? (I don't know what all this switch kills on a 90MY) YES, when the inertia is tripped on this car all electrical is completely dead, nothing.
- did you test for a good coolant temperature sensor and connection? YES, I just replaced, there is power going to the sensor
(click thumbnail to see 90MY Crank Sensor schematic)
Dynamic crank position sensor test
Crankshaft sensor wires, R (red) and U (blue), connect to the LOW POWER ECU at pins LI59-13 and LI59-24.
- Find your ECUs,
- locate the LOW POWER ECU,
- locate the afore mentioned pins,
- connect the probes of a voltmeter set on the AC function to these pins,
- have someone crank the engine, and
- check to see if you are getting a pulsed signal.
- the wiring from the ECU to sensor connector,
- the gap between sensor and gear teeth (should be 0.018 to 0.042 inch) or
- the Crank Sensor itself.
I'm reminding myself here that you should find the WB wire (white/black tracer) connecting the amplifier to the coil, connect a voltmeter to the coil at its negative (-) terminal end and ground, set the scale to AC volts, have someone crank the engine and check to see if you are getting a fluctuating signal. You most probably are not.
The amplifier acts as a switch, periodically shunting the coil to ground. The capacitor is provided to smooth out the transients (or spikes) in coil's voltage waveform.
o
#9
Amplifier ground
"Curiouser and curiouser", said Alice.
Hmmm ... It reads to me that your primary winding of your coil is getting juice and that circuit is pulsing.
Now it seems there is something wrong with your secondary circuit.
It's odd to read the secondary (high resistance) wiring of the coil goes through the primary winding to ground, but that seems how Haynes explains to test it.
1. There is a B (Black) wire coming from the amplifier terminal LI28 that connects directly to the ground, LIG30. I don't know where this is located, so you'll have to trace it back from terminal LI28.
There are 3 other connections to this ground: a diagnostic socket terminal, the shield surrounding the crank sensor and oxygen sensor, and more disturbingly, pin LI58-24 of the HIGH POWER end of your Engine Management ECU.
Ensure this LIG30 is a good ground. Of course, all grounds are important - they constitute 1/2 of your car's wiring.
2. I've searched and found no mention of your replacing sparking plug wires and more importantly, the coil to distributor cap wire. Could yours be defective (a possible break in it)?
still from Tim Burton's Alice in Wonderland
o
Hmmm ... It reads to me that your primary winding of your coil is getting juice and that circuit is pulsing.
Now it seems there is something wrong with your secondary circuit.
It's odd to read the secondary (high resistance) wiring of the coil goes through the primary winding to ground, but that seems how Haynes explains to test it.
1. There is a B (Black) wire coming from the amplifier terminal LI28 that connects directly to the ground, LIG30. I don't know where this is located, so you'll have to trace it back from terminal LI28.
There are 3 other connections to this ground: a diagnostic socket terminal, the shield surrounding the crank sensor and oxygen sensor, and more disturbingly, pin LI58-24 of the HIGH POWER end of your Engine Management ECU.
Ensure this LIG30 is a good ground. Of course, all grounds are important - they constitute 1/2 of your car's wiring.
2. I've searched and found no mention of your replacing sparking plug wires and more importantly, the coil to distributor cap wire. Could yours be defective (a possible break in it)?
still from Tim Burton's Alice in Wonderland
o
#10
#11
Dynamic (on car) Coil Test
- I am still suspicious of the high tension lead between coil and distributor cap. I've known them to "open" internally if you bend them just right.
- Is your GROUND good between the engine block and -tive battery terminal?
th_1990VDPIgnCoil-Amp-ECUschem.jpg?t=1315671067 (clickable thumbnail)
I would isolate the coil and try the following. See above schematic before reading the following.
Dynamic (on car) Coil Test
- Turn ignition key to the off position and remove it.
- Disconnect the 2 WB wires from LI27, the -tive terminal of coil.
- Disconnect the WK wire to the amplifier from the coil and put some electrical tape on the disconnected end. Do not allow it to touch GROUND.
- Maybe for now even disconnect the capacitor end connected to LI26, the +tive coil terminal. Keep WK wire connected to coil.
- Connect a NEW wire from the -tive terminal of the coil and connect it either to a good ground or better still to the -tive battery terminal.
- Remove the coil to dist cap h.t. lead at the dist cap end and connect your spark plug tester to this end. Connect spark tester clamp to a good ground.
- Have an assistant turn the ign key to the on, but not the start position. There should be 12V at coil terminal LI26 every time the key is turned on. There should be a spark jump across the gap of the tester every time the key is turned off.
- Naturally, if you have a spare switch, you could wire it to the +tive coil terminal and connect the harness WK wire to it. This way you don't need an assistant. You can just turn the ign key on and energize/de-energize the coil from the remote switch.
- If you do it this way you've reduced the risk of getting shocked from high voltage because you are pretty much isolated from the secondary. If you have rubber gloves, wear them anyway just in case there is something wrong with the coil.
#12
#13
Here we go. Thanks again trick for your input. 2 issues I have had. There was intermittent spark. The tests I did, from your posts all showed voltage. I have, somehow regained spark, like lightning as well. Hurricane Irene came in on a Sunday, it was Monday the car wouldn't start, after weeks of replacing everything 3 times, it appears there was at least 10 gallons of water in the tank. I removed it all, got the car to start and run smoothly. She stalled. I continued at least another 30 minutes with starter fluid, and cranking. No spark again. While it was running I was able to pull a code 24. Ignition ECU Amp issue. I went back in to try another coil, when the little wire from the capacitor came out. So I will go and get another tomorrow. How did the water get in? The little hole that drains the water was plugged up. When I opened the cover the water was to the top above the cap, I assume it got in through an air vent somewhere in the cap. I actually cleaned that out 3 weeks ago monday, it never occured to me water could get in the tank from there. Clear out that little hole in the rubber that surrounds the cap folks. After i get a new capacitor, the car by all right should start. I'll be sure to let you know tomorrow
#14
Unbelievable
If you have followed along these threads about cranking no start, cps etc..then you surely dread if it ever happens to you. 2 Fuel pumps, new filter, new regulator, 5 Used But Working CPS's, 4 Working Coils, 3 used but working amplifiers, 1 Working ECU, 5 Brand New Relays. I drained between 12 and 14 gallons of fouled gas/water. No spark still. My last post was last Thursday or Friday, basically waving the white flag and ready to burn it.
Today I finally said I will have it towed 30+ miles to a friend of mine, that can do more than I. Its been 4 weeks as of yesterday this car will not start. 93$ tow fee. The car got there at 10:09a NY Time this morning. My friend called me at 10:23 and said, "car started right up." He has had it all day, it is now 7:41p, he started it all day. His last text to me 35 minutes ago was simple. It said, "car is running flawlessly." They say there is a reason for everything, I am so anxious to find out the reason for this episode!
Today I finally said I will have it towed 30+ miles to a friend of mine, that can do more than I. Its been 4 weeks as of yesterday this car will not start. 93$ tow fee. The car got there at 10:09a NY Time this morning. My friend called me at 10:23 and said, "car started right up." He has had it all day, it is now 7:41p, he started it all day. His last text to me 35 minutes ago was simple. It said, "car is running flawlessly." They say there is a reason for everything, I am so anxious to find out the reason for this episode!
#15
#17
#18
I am at it again with this black 90 vdp. I am not so sure the problems we have addressed above were my issue. I hate making these posts long, but as much information I can give can help me finally resolve this ongoing issue. I remember while tackling all the above troubleshooting suggestions, that at one point the fuel stopped pumping out of the rail and the fuel pump just stopped. Cut to the chase, it is an ongoing issue and causes this vehicle to stall out and not restart. I have 2 fuel pumps that both work while bench testing. I also have 12 volts at the connectors that attach to the pump when you first turn the key, it is for a split second. That is what you hear when you turn the key. This is where I am stalled. I do not hear that fuel pump at the turn of the key. Either one of them. And they both work, and I am getting voltage to those pumps. Where else may I look next. I changed out the relay with a known working one as well. Any help, of course would be appreciated.
#19
Mmmmm, not sure about the '40, but our earlier cars had the "earth" of the fuel pump relay controlled/triggered by the ECU, and the 6CU was a mongrel for fuel pump control circuit issues, haha, teh 16CU was better, of course that is the V12's, but all systems are basically identical.
You have 12v TO the pump, OK, got that, and the EARTH of that relay is controlled by the ECU, hence the timer effect we all know of.
I would by-pass that relay, which removes the relay and ECU from fuel pump control. BE BLOODY CAREFUL, coz when by-passed the pump will run at ALL times the ignition is ON, and NO enertia safety etc is operational.
If that fixes it, the ECU is suspect, OR the signal from the engine to inform the ECU that there is ignition activity, so pump operation is required. Where that comes from, NO IDEA on a '40, sorry.
You have 12v TO the pump, OK, got that, and the EARTH of that relay is controlled by the ECU, hence the timer effect we all know of.
I would by-pass that relay, which removes the relay and ECU from fuel pump control. BE BLOODY CAREFUL, coz when by-passed the pump will run at ALL times the ignition is ON, and NO enertia safety etc is operational.
If that fixes it, the ECU is suspect, OR the signal from the engine to inform the ECU that there is ignition activity, so pump operation is required. Where that comes from, NO IDEA on a '40, sorry.
Last edited by Grant Francis; 11-26-2011 at 04:42 AM.
