XJ6 & XJ12 Series I, II & III 1968-1992

New Brake Pads up front


  #1
Old 02-14-2009, 04:44 PM
Senior Member
Thread Starter
Join Date: Dec 2008
Location: Littleton Colorado
Posts: 143
Likes: 0
Received 0 Likes on 0 Posts
Default New Brake Pads up front

I had my rear rotors and pads done at a shop with organic pads. I now have new organic pads for the front brakes and wonder if anyone has a secret on how to depress the caliper without removing it. The shop manual simply says to pull a couple pins, slide the old pads out, then slide the new ones in. The guy at the parts counter said to pry open the caliper to make room for the new (and thicker) pad. Makes sense, how can I safely do this.... and is this a do it your self job? I am sure it is, but I have learned to ask here BEFORE doing anything. Thanks in advance.

  #2
Old 02-14-2009, 07:05 PM
Veteran Member
Join Date: Mar 2008
Location: Pacific Northwest USA
Posts: 20,151
Received 6,559 Likes on 4,863 Posts
Default

I just use a big screwdriver to lever the pistons in. Don't mangle the rubber dust seals, though.

Cracking open the bleeder makes it very easy, of course....just make sure to close it while you are still pushing the piston, not after you release. .....or you'll suck air back it.

Actually, if it hasn'r been done in the last two years, you might as well flush.bleed the brake fluid while you're getting dirty.

Cheers
DD

  #3
Old 02-14-2009, 08:56 PM
Join Date: Sep 2008
Location: Damon /Houston, Texas
Posts: 7,025
Received 1,839 Likes on 1,196 Posts
Default

Doug,
You left out 1 important point,
It HAS to be a Jaguar approved screw driver...

  #4
Old 02-15-2009, 07:27 AM
Jose's Avatar
Veteran Member
Join Date: Mar 2007
Location: Florida
Posts: 5,826
Received 1,339 Likes on 1,089 Posts
Default

I don't have a crystal ball either but I have a crystal Skull, and with speakers!

Attached Thumbnails New Brake Pads up front-crystal-skull.jpg
  #5
Old 02-15-2009, 04:14 PM
Senior Member
Thread Starter
Join Date: Dec 2008
Location: Littleton Colorado
Posts: 143
Likes: 0
Received 0 Likes on 0 Posts
Default

Perfect, thank you.

  #6
Old 03-01-2009, 05:35 PM
Senior Member
Thread Starter
Join Date: Dec 2008
Location: Littleton Colorado
Posts: 143
Likes: 0
Received 0 Likes on 0 Posts
Default

What if I do accidentally poke a hole in the dust seal? The pin that holds the rod in poked a little pin hole in the rubber as I was removing it.....

  #7
Old 03-01-2009, 10:14 PM
Veteran Member
Join Date: Mar 2008
Location: Pacific Northwest USA
Posts: 20,151
Received 6,559 Likes on 4,863 Posts
Default

Originally Posted by Walter1982 View Post
What if I do accidentally poke a hole in the dust seal? The pin that holds the rod in poked a little pin hole in the rubber as I was removing it.....

If I hadn't said anything it probably wouldn't have happened !

Not the end of the world. At some point you'll overhaul the calipers, or buy rebuilt ones, which means new dust seals. Of course keeping the innards of the caliper clean is important for longer life but there not much you can do about it now. Live with or remove the caliper and replace the seal....which comes in an overhaul package :-)

Of course the most responsible answer is "This is brakes....safety related. Don't dive until you replaced the dust seal".


Cheers
DD
