Penetrating oil
#1
Penetrating oil
I recently received this information from a friend, and while I have not confirmed the data, I think it is worth passing along. It was attributed to Machinist Workshop Magazine.
Nuts and bolts were rusted to a uniform degree in a brine solution.
Treatment Breakout Torque (lbs)
None 516
WD 40 238
PB Blaster 214
Liquid Wrench 127
Kano Kroil 106
ATF/Acetone (50/50) 50
I don't know how many samples were tested or what the variation was, but still, it's interesting.
Nuts and bolts were rusted to a uniform degree in a brine solution.
Treatment Breakout Torque (lbs)
None 516
WD 40 238
PB Blaster 214
Liquid Wrench 127
Kano Kroil 106
ATF/Acetone (50/50) 50
I don't know how many samples were tested or what the variation was, but still, it's interesting.
#2
I've been mixing my own penetrating oil from that 50/50 mix for 25 years and it works! I don't even own another type of P.Oil.
I have a spray bottle that I picked up at a swap meet a few years back that I can pressurize with shop air and spray the magic fluid on a part that cannot be reached by getting above & dripping a few drops on it.
Do it.
I have a spray bottle that I picked up at a swap meet a few years back that I can pressurize with shop air and spray the magic fluid on a part that cannot be reached by getting above & dripping a few drops on it.
Do it.
Last edited by maxwdg; 02-15-2013 at 10:06 AM.
The following users liked this post:
RJ237 (02-15-2013)
#3
The following users liked this post:
Frog (02-21-2013)
#5
#6
Seems like PB Blaster is a miracle of modern marketing. At least Kroil is at the better end but so is the venerable Liquid Wrench.
The ATF mixes have been talked about for years. I wonder why some company doesn't just switch their formula.
let the fingers do the walking ...
Ed's Red' Bore Cleaner
Bore cleaner recipe
1 part Dexron II, IIe or III ATF, GM Spec. D-20265 or later.
1 part Kerosene - deodorized, K1
1 part Aliphatic Mineral Spirits, Fed. Spec. TT-T-2981F, CAS
#64741-49-9, or may substitute "Stoddard Solvent", CAS #8052-41-3, or
equivalent, (aka "Varsol")
1 part Acetone, CAS #67-64-1.
we've been using atf and kerosene in our parts washer for years, works good.
The ATF mixes have been talked about for years. I wonder why some company doesn't just switch their formula.
let the fingers do the walking ...
Ed's Red' Bore Cleaner
Bore cleaner recipe
1 part Dexron II, IIe or III ATF, GM Spec. D-20265 or later.
1 part Kerosene - deodorized, K1
1 part Aliphatic Mineral Spirits, Fed. Spec. TT-T-2981F, CAS
#64741-49-9, or may substitute "Stoddard Solvent", CAS #8052-41-3, or
equivalent, (aka "Varsol")
1 part Acetone, CAS #67-64-1.
we've been using atf and kerosene in our parts washer for years, works good.
Last edited by plums; 02-15-2013 at 12:40 PM.
Trending Topics
#8
#9
...............
1 part Dexron II, IIe or III ATF, GM Spec. D-20265 or later.
1 part Kerosene - deodorized, K1
1 part Aliphatic Mineral Spirits, Fed. Spec. TT-T-2981F, CAS
#64741-49-9, or may substitute "Stoddard Solvent", CAS #8052-41-3, or
equivalent, (aka "Varsol")
1 part Acetone, CAS #67-64-1..................
1 part Dexron II, IIe or III ATF, GM Spec. D-20265 or later.
1 part Kerosene - deodorized, K1
1 part Aliphatic Mineral Spirits, Fed. Spec. TT-T-2981F, CAS
#64741-49-9, or may substitute "Stoddard Solvent", CAS #8052-41-3, or
equivalent, (aka "Varsol")
1 part Acetone, CAS #67-64-1..................
After I saw you'd made several posts to the thread, I made the mistake of thinking plums must have been recommending this as a cocktail recipe.
My nuts are shiny and slack now but I'm going to have the mother of all hangovers in the morning.
Graham
The following users liked this post:
Spurlee (02-16-2013)
#11
ROTFLMFAO ... doesn't happen often
#12
#13
WD-40 has a new line on products and one of them is Rust Release Penetrant Spray. I have not used it but I think it is worth trying the product. I have been using PB Blaster for years for rusted or stuck nuts and bolts and it has always done its job.
I recently received this information from a friend, and while I have not confirmed the data, I think it is worth passing along. It was attributed to Machinist Workshop Magazine.
Nuts and bolts were rusted to a uniform degree in a brine solution.
Treatment Breakout Torque (lbs)
None 516
WD 40 238
PB Blaster 214
Liquid Wrench 127
Kano Kroil 106
ATF/Acetone (50/50) 50
I don't know how many samples were tested or what the variation was, but still, it's interesting.
Nuts and bolts were rusted to a uniform degree in a brine solution.
Treatment Breakout Torque (lbs)
None 516
WD 40 238
PB Blaster 214
Liquid Wrench 127
Kano Kroil 106
ATF/Acetone (50/50) 50
I don't know how many samples were tested or what the variation was, but still, it's interesting.
#14
Cable lube
I mix my own "Bolt Buster" as a 50/50 ATF and Acetone mix and it works great.
Last summer I had a sticking shift cable on my boat and it's replacement would be quite extensive. A boating buddy suggested that I make a funnel arrangement and work straight ATF down the cable. It restored the cable to perfect working order in a couple of hours!
Last summer I had a sticking shift cable on my boat and it's replacement would be quite extensive. A boating buddy suggested that I make a funnel arrangement and work straight ATF down the cable. It restored the cable to perfect working order in a couple of hours!
#16
#18
Join Date: Oct 2007
Location: PHX some of the time
Posts: 116,700
Received 6,243 Likes
on
5,444 Posts
#19
#20
To be a bit pedantic you need to differentiate between corrosion which implies some sort of chemical reaction and solution where the material involved remains chemically unchanged although its physical appearance may change.
Acatone dissolves some but not all plastics so it will alter the appearance of paint finishes etc.
ATF gets on quite happily with a variety of metals and plastics inside the gearbox.
In this application I suspect the acetone is simply used as a carrier, diluting and lowering the viscosity of the ATF to get it well into the joint/thread in question, then it evaporates.
Apart from painted surfaces I don't think the quantity involved is a risk to anything.
Acatone dissolves some but not all plastics so it will alter the appearance of paint finishes etc.
ATF gets on quite happily with a variety of metals and plastics inside the gearbox.
In this application I suspect the acetone is simply used as a carrier, diluting and lowering the viscosity of the ATF to get it well into the joint/thread in question, then it evaporates.
Apart from painted surfaces I don't think the quantity involved is a risk to anything.
Last edited by steveinfrance; 02-22-2013 at 02:13 AM. Reason: mplies = implies!!
