Hi, does anyone know why my air bag light randomly starts flashing on my dashboard ?
It seems to not be constant...but it is regular
It flashes once pauses then 9 times so code is 1-9
I have had my hand under the seat and checked connections.....
Your assistance is appreciated as my mot now due



If memory serves, that will be the clock spring in the steering wheel.

Can be cleaned but better to replace.



My air bag light is flashing code 23 (a sequence of two flashes then three flashes). Can anyone tell me what fault this signifies and perhaps what the cure is?



The air bag light in my 2002 manual shift 2.5 is flashing code 23 - a sequence of two flashes then three flashes. Can anyone tell me what fault this indicates and perhaps how to fix it? Thanks in advance!



I have attached a sheet listing Jaguar air bag codes. My problem was a CODE 33. I had to replace the drivers seat belt buckle.



Vern: thanks very much for posting that code list - because it helped me solve the problem. The code 23 is for the passenger side airbag wiring. This car has had only one fault, a minor one, in all the years of ownership: the passenger side airbag light above the glovebox would come on occasionally - with no one and no weight in the seat. It could always be extinguished by simply pressing the connector under the seat (the airbag light that is the concern in this thread for me is the light in the instrument panel in front of the driver - this has never been on before - which is why I thought it might be something more serious like the clockspring).
Well, your help pointed me to the same connector under the passenger seat. I simply played a bit with the connector and wires, started the engine - fully expecting the driver's side airbag light to still be on - but mirabile dictu! no light!
The permanent solution is to probably disconnect the connector and use some contact spray on it and reconnect but I now know that there is no serious issue and I know how to solve it if the light comes on again. Many thanks!
These are wonderful cars; we have three of them - two manuals and an automatic (Sportwagon) - we have found them to be absolutely reliable and a joy to own and drive.



Glad to be of help. They are fine automobiles. I have three and have just ran up on a chance for a 1977 XJ-12. I have always wanted a V-12 and this just might be my chance.
Regards
