Transmission fluid check on xjs
#1
#2
Run the car up to temperature, park it up and put your foot on the brake.
At tick over run through all the gears several times then leave it in Park.
With the engine still running pull the dip stick (brown handle below the right hand side cross brace, close to the fire wall, bit tricky so make sure you have a rag to hand), wipe it, reinsert it and pull it again and read it. Do this several times and take an average reading. Once you have determined the level and you decide that you need to top it up simply pour the correct amount (and grade) of ATF down the dip stick tube; using a long necked funnel helps a lot.
At tick over run through all the gears several times then leave it in Park.
With the engine still running pull the dip stick (brown handle below the right hand side cross brace, close to the fire wall, bit tricky so make sure you have a rag to hand), wipe it, reinsert it and pull it again and read it. Do this several times and take an average reading. Once you have determined the level and you decide that you need to top it up simply pour the correct amount (and grade) of ATF down the dip stick tube; using a long necked funnel helps a lot.
The following users liked this post:
paulyling (02-07-2016)
#3
Run the car up to temperature, park it up and put your foot on the brake.
At tick over run through all the gears several times then leave it in Park.
With the engine still running pull the dip stick (brown handle below the right hand side cross brace, close to the fire wall, bit tricky so make sure you have a rag to hand), wipe it, reinsert it and pull it again and read it. Do this several times and take an average reading. Once you have determined the level and you decide that you need to top it up simply pour the correct amount (and grade) of ATF down the dip stick tube; using a long necked funnel helps a lot.
At tick over run through all the gears several times then leave it in Park.
With the engine still running pull the dip stick (brown handle below the right hand side cross brace, close to the fire wall, bit tricky so make sure you have a rag to hand), wipe it, reinsert it and pull it again and read it. Do this several times and take an average reading. Once you have determined the level and you decide that you need to top it up simply pour the correct amount (and grade) of ATF down the dip stick tube; using a long necked funnel helps a lot.
#4
The following users liked this post:
ronbros (02-06-2016)
#5
Join Date: Mar 2008
Location: Pacific Northwest USA
Posts: 24,739
Received 10,749 Likes
on
7,100 Posts
The following 2 users liked this post by Doug:
Grant Francis (02-06-2016),
ronbros (02-06-2016)
#7
Trending Topics
#8
The following users liked this post:
Grant Francis (02-07-2016)
#9
#10
The following users liked this post:
Grant Francis (02-07-2016)
