XJ6 & XJ12 Series I, II & III 1968-1992

1985 Jag cylinder head nut Torque?


  #1
Old 03-11-2009, 09:29 AM
Junior Member
Thread Starter
Join Date: Mar 2009
Posts: 8
Likes: 0
Received 0 Likes on 0 Posts
Default 1985 Jag cylinder head nut Torque?

Hi I am new to the jag World just purchased a 1985 with the 4.2 does anyone know the torque on the cylinder head nuts and the pattern it should be torqued . Thanks for any help.

  #2
Old 03-14-2009, 11:35 AM
Keith's Avatar
Senior Member
Join Date: Jan 2008
Location: Just outside of Little Rock, Arkansas
Posts: 216
Likes: 0
Received 8 Likes on 8 Posts
Default

Apparently no one knows, or cares, but the answer is in the service manual. The head nuts are torqued from 52 to 54 lbf FT. Give me you email address and I'll send you a diagram straight from the service manuel, showing the torque sequence.

  #3
Old 03-16-2009, 05:31 PM
Junior Member
Thread Starter
Join Date: Mar 2009
Posts: 8
Likes: 0
Received 0 Likes on 0 Posts
Default Thanks

Thanks for the info I just got an 85 recently and it is missing 2 of the original nuts .someboby replaced with some cheap locking nuts ..so I was hopen to find a couple of original ones and retorque everything down

  #4
Old 03-16-2009, 06:48 PM
Keith's Avatar
Senior Member
Join Date: Jan 2008
Location: Just outside of Little Rock, Arkansas
Posts: 216
Likes: 0
Received 8 Likes on 8 Posts
Default

Their pretty easy to locate. Try David Boger, he posts on this site and everydayxj.com. If you want the diagram, pm me with your email address.

  #5
Old 03-16-2009, 08:38 PM
Join Date: Nov 2006
Location: Glasgow, Scotland UK
Posts: 47,343
Received 8,897 Likes on 4,091 Posts
Thumbs up

Name:  car22.jpg
Views: 65
Size:  16.5 KB


Nice one Keith

  #6
Old 03-16-2009, 09:28 PM
Keith's Avatar
Senior Member
Join Date: Jan 2008
Location: Just outside of Little Rock, Arkansas
Posts: 216
Likes: 0
Received 8 Likes on 8 Posts
Default

Jim, your killin me with your icon! Every time I look at the double eyes and mouth I get disoriented. Guess it helps being a little off, to own a Jag, and realy crazy to own more than one. )

  #7
Old 03-21-2009, 02:25 AM
Junior Member
Join Date: Mar 2009
Location: St. Louis, MO
Posts: 8
Likes: 0
Received 0 Likes on 0 Posts
Default

Keith,
Hi, Would you happen to have the service manual for '99 XJ8?
If yes, would you send it to [email protected]?

  #8
Old 03-21-2009, 08:28 AM
Keith's Avatar
Senior Member
Join Date: Jan 2008
Location: Just outside of Little Rock, Arkansas
Posts: 216
Likes: 0
Received 8 Likes on 8 Posts
Default

Sorry, only 85 XJ-6 and 95 XJS

  #9
Old 03-21-2009, 08:29 AM
Keith's Avatar
Senior Member
Join Date: Jan 2008
Location: Just outside of Little Rock, Arkansas
Posts: 216
Likes: 0
Received 8 Likes on 8 Posts
Default

Sending an entire service manual would be a pretty long ordeal. Your best be would be to check ebay for one of their service manuals on disk, usally pretty cheap.

  #10
Old 03-22-2009, 03:18 PM
JackJohn's Avatar
Senior Member
Join Date: Sep 2008
Location: Richmond, TX.
Posts: 592
Received 101 Likes on 79 Posts
Default

Terry, you may have already found this, if not, Christo has your manual in a thread here in the General Tech Help.

  #11
Old 03-23-2009, 07:40 AM
Keith's Avatar
Senior Member
Join Date: Jan 2008
Location: Just outside of Little Rock, Arkansas
Posts: 216
Likes: 0
Received 8 Likes on 8 Posts
Default

I think his manuals are for the later model cars, not an 88, but might be wrong.

  #12
Old 03-23-2009, 06:46 PM
JackJohn's Avatar
Senior Member
Join Date: Sep 2008
Location: Richmond, TX.
Posts: 592
Received 101 Likes on 79 Posts
Default

You're right Keith, sorry about the misinformation.
