IRS Cage
#1
IRS Cage
This is a fabricated tubular IRS Cage that uses the same Jaguar stock mounting points but allows for easier access to the brakes than the stock pressed steel version. In this case it has an upper arm and will use CV joints. Doesn't have to use CV's. I could just run the stock Jag drive shaft with the Jag hub but where's the fun in that.. Also uses longer tubular radius rods that triangulate the centre line of the the lower arms. The hubs are slightly modified Jaguar design with added upper mounting point for the upper arm. Designed in CAD and then built in the UK. This is not an advertisement. I think the company who made it for me found the project to be time sink on their part.
Once it's fitted to the car I'll attach the Go Pro and see how it performs.
Once it's fitted to the car I'll attach the Go Pro and see how it performs.
The following 13 users liked this post by Como:
Daf11e (07-16-2019),
Doug (07-16-2019),
geneo (07-20-2019),
Jag7651 (07-16-2019),
littlelic69 (07-16-2019),
and 8 others liked this post.
The following users liked this post:
Roger Mabry (07-16-2019)
#3
Join Date: Jul 2012
Location: Walnut Creek, California
Posts: 6,796
Received 2,399 Likes
on
1,880 Posts
#4
Join Date: Mar 2014
Location: Tehama County, California, USA
Posts: 25,180
Received 8,947 Likes
on
5,294 Posts
#7
This hasn't been tested in the car yet so its all purely a CAD experiment until that time to see if it works. You could contact Wisbech Engineering in the UK if you were after the cage and wanted to use the standard Jaguar driveshaft and lower arm. This design - upper arm with CV joints and centrally located radius rods - is more like a multi link so will remove some of the rear steer affect that you get from the factory designed more compliant radius rod bushes so it needs some trial and error testing including with and without an anti roll bar. My car is going through a full strip down so there is room to do some body work mods if necessary. I'm hoping it wont be as all the mounting points are taken from the pressed steel factory mounting cage. It's not an off the shelf replacement or a new idea as the Cobra and hot rod guys have been using hard mounted tube cages with Jag IRS for quite some time to reduce fore and aft movement. The new idea is to try and use an upper arm and CV joints for the driveshaft. Early days thanks for the encouragement. The Cobra guys also use an alloy housing Salisbury 4HU which saves about half the weight of the rear end.
