Hi, I am trying to fix my bodged up boot lock which has arrived today but
it may as well be a bunch of 0' and 1's.
I am not sure how to put this together in order for my existing key to work. I would really appreciate any assistance. Possible YouTube clips would be great
Thanks, Zack
it may as well be a bunch of 0' and 1's.
I am not sure how to put this together in order for my existing key to work. I would really appreciate any assistance. Possible YouTube clips would be great
Thanks, Zack
#2
TIBBE locks
I have not needed to do this, but the technical designation for these locks is "TIBBE". A quick search reveals:
doorlockbld.htm
Best of luck, keep us posted.
doorlockbld.htm
Best of luck, keep us posted.
The following users liked this post:
michaelh (10-07-2016)
#3
#4
Join Date: Apr 2014
Location: Jersey, Channel Islands
Posts: 4,077
Received 2,291 Likes
on
1,503 Posts
The following users liked this post:
GGG (10-08-2016)
#5
#7
Hi, I am getting even more confused. Do the latest comments mean that I have purchased the wrong thing? I have taken the plastic covers off and am just about to have a look at what is left of the original lock.
I have found a YouTube clip of a guy putting together a ford boot lock which is similar but obviously not the same. If anybody has info regarding the building of the lock I will be indebted for life
I have found a YouTube clip of a guy putting together a ford boot lock which is similar but obviously not the same. If anybody has info regarding the building of the lock I will be indebted for life
Trending Topics
#8
Join Date: Apr 2014
Location: Jersey, Channel Islands
Posts: 4,077
Received 2,291 Likes
on
1,503 Posts
My Friday night red wine logic...
I can't find the maximum recurrence for a particular cut, but assuming 4 (mine has 4 instances of a '2' cut) then 12 wafers, 4 of each, will cover all combinations.
GZ, you haven't got the wrong thing. See above.
From what I've read, the wafers have 1,2 or 3 stamped on them. You need to assemble them in the barrel to match the order on your key. See here:
http://www.triple-c.com/How_To_Read_..._Key_Codes.cfm
for how to read the key code.
I can't find the maximum recurrence for a particular cut, but assuming 4 (mine has 4 instances of a '2' cut) then 12 wafers, 4 of each, will cover all combinations.
GZ, you haven't got the wrong thing. See above.
From what I've read, the wafers have 1,2 or 3 stamped on them. You need to assemble them in the barrel to match the order on your key. See here:
http://www.triple-c.com/How_To_Read_..._Key_Codes.cfm
for how to read the key code.
Last edited by michaelh; 10-08-2016 at 12:15 PM.
#9
Stage 1
I have taken the old barrel out and it has been slightly abused. Was quite pleased with myself as I managed to do this without breaking anything.
I am planning to put together the new one tomorrow. However, as previously stated I have no instructions or reference material on how to assemble this type of lock. There are lots of parts that have come with the new barrel and I am not too sure where many of them go.
Thank you for your assistance fellas. It has helped a lot, Zack
I am planning to put together the new one tomorrow. However, as previously stated I have no instructions or reference material on how to assemble this type of lock. There are lots of parts that have come with the new barrel and I am not too sure where many of them go.
Thank you for your assistance fellas. It has helped a lot, Zack
#10
Join Date: Apr 2014
Location: Jersey, Channel Islands
Posts: 4,077
Received 2,291 Likes
on
1,503 Posts
LOL Just ever so slightly
There's a Jaguar TSB here:
http://www.jagrepair.com/images/TSB/...XJ40/76-64.pdf
courtesy of Gus and motorcarman. It's old, but it should help as a guide.
Good luck!
M
There's a Jaguar TSB here:
http://www.jagrepair.com/images/TSB/...XJ40/76-64.pdf
courtesy of Gus and motorcarman. It's old, but it should help as a guide.
Good luck!
M
#11
Hi, I have been pi##ing about with the lock for the best part of the day and have got nowhere really. I have dyspraxia which isn't helping with working out the key configuration and then the placing of the Discs. There also seems to be a metal pin missing. I have one but the diagram that I was very grateful to receive
shows two.
shows two.
#12
Zen and the art of boot lock maintenance. Well I've only gone and done it. I feel like making a rather emotional speech (thank you to all who have supported me along the way etc...). It only took around 7 hours and I still have to put plastic covers back but I have managed to build the lock and it works. It is a little stiff so I will add some grease but I now have a boot lock.
The car is at the painters next week so I will get him to tidy it up and with a new badge, it should be ok
Cheers for help, Zack
The car is at the painters next week so I will get him to tidy it up and with a new badge, it should be ok
Cheers for help, Zack
The following users liked this post:
Norri (10-10-2016)
